Hydra: Self-Rearranging Robot

Fully Designed · 30 Units Manufactured · In-Simulation Controller · RL Form-Based Controller

Icarus: Humanoid Robot

Fully Designed · Hip-Down Manufactured · Stress-Tested

FINGIE: 27 DoF Robotic Hand

Fully Designed · Fully Manufactured · Inverse-Kinematics

Dum-E: Modular Robotic Arm + Generalized End Effector

Fully Designed · Fully Manufactured · Custom PCBs · Inverse-Kinematics

Multi: A 17-in-1 Pocket Tool

Fully Designed · Fully Manufactured · Everyday Use

Axis: Autonomous Inverted Double Pendulum

Fully Designed · Fully Manufactured · Custom PCBs · In-Simulation Controller

Falcon: Phone-Deployed Drone

Fully Designed · Fully Manufactured

Apogex: High Altitude Rockoon

Fully Designed · Fully Manufactured · Autonomous Controller · Launched to 36km

Hydra: Self-Rearranging Robot

Motivation

Humans have shaped the world to suit our needs, creating a utilitarian environment we can inhabit. Anthropomorphic robotics, therefore, serves as a natural bridge to generalized robotics—capable of using the same tools and spaces, and thus performing the same tasks as we do. However, robotics has the potential to achieve much more. What if robots weren't constrained by form? What if they could navigate any conceivable space, grasp objects of any shape, and serve and manipulate any tool? Amorphic robotics opens up every niche in our world — offering possibilities beyond what evolution could provide.

Design Overview

All self-rearranging robots currently are prohibitively large, move very slowly, and have horribly insufficient control systems. I want to solve all of these problems. I decided to use edges and nodes. Nodes have four electromagnets which can be controlled, and edges can rotate, extend, and flex, with magnetic terminals on each side. This enables self-rearrangement and unrestricted movement. The mechanical and electrical design allows for sub-cm length of edges and 10mm width in each node-edge subsystem.

Some Challenges

This project is ongoing, so not all of the challenges are known yet, but below are a few that caused me pain...

Permanent Magnets: Since the batteries are self-contained within the nodes (and also communicate power via pogo pin contact points to the edges), we want to minimize power usage. Thus, we don't want energy draw when the electromagnets are in contact (i.e. on). So, instead of traditional electromagnets which are on when current is sent through them, I had to use permanent magnets which are off when current is sent through them. Unfortunately, these do not exist for purchase in the size I need, so I manufactured them. To do this, I designed and manufactured a spooling mechanism and computed the solenoid dimensions to generate a specific holding force of the magnet. This necessary holding force was computed through stochastic guarantees on the cumulative force of lattice structures that the overall system could generate. This garauntee is quite cool as there is feedback between torque profiles in the motor, the weight of the motors, and the peak carrying weight of the magnets and their own weight so it turns into an optimization problem! Document Describing Method
Position Control of Motors: The motors used are micro-DC motors which cost about $1 each with custom planetary gearboxes (for the motor responsible for rotation) and wormgear drives (for the motor responsible for extension/flexion) and unfortunately are too small to have any encoder setup that I could simply buy. As such, I had to use coin encoders (which only have an accuracy of 180 degrees) and embed them into the back-shaft inside the micro-DC motor. To do this, I had to reconstruct the shell of the motor, which required me to bend zinc sheets very precisely and mount the encoders as part of the body of the motor.
Parallelized Simulation: Previous attempts at large-scale self-reassembling robots generally used search algorithms and basic movement primitive structures. But, based on work at the AMBER Lab, I was curious about how we could reduce the high-dimensional decision space of this control system (since it has massive state spaces) using reinforcement learning (RL). I thus set up IsaacSim in a Dockerized container and hosted it on a virtual GPU (since I cannot afford the multi-thousand dollar price tag to buy one). I wrote custom physics for the attachment and reorganization of nodes and edges. I'm currently experimenting with different hierarchically stacked RL-based controllers.

Icarus: Humanoid Robot

Challenges

You'll notice that I did not use the typical cylindrical motors to actuate the joints. This was due to cost - each of those (e.g. Unitree B1) are $8,000+ which are personally unaffordable. Instead, I decided to build in the motors to the skeletal structure of the robot. This posed a massive mechanical engineering challenge as parameterizing the model is now nearly impossible. I built an API that plugs into my Fusion 360 for this that draws on available dimensions from Servocity, where I sourced the motors. This enables parameterization of limb lengths so that I can optimize stress profiles in FEA in Fusion 360.

Objectives

A main objective that I gave myself for this project was to try to mimic the motion patterns of humanoid joints as closely as possible. A good example of this is the scapular motion, which does not follow a typical fixed radius arc. Instead, it moves approximately linearly until an inflection point at which it translates to an arc of approximately fixed radius. To mimic this, I used linear rails with linear bearings with pendulum-esque structures actuated by a central motor. On the linear rails, there are stiff springs. As the linear rail (attached to the shoulders) moves up the rail linearly, they quickly collide with the springs, which then translate the motion to an arc.

Similarly, shoulder abduction (generally controlled by the supraspinatus and lateral middle deltoid muscles) is controlled by linear rails themselves actuated by in-line motors attached to the spine via universal joints, allowing for a full range of motion.

Optimizations

The entire assembly had to be low-cost. Because of the in-line motor design and the entirely custom gearboxes, it is able to be assembled at the cost of approximately $3,000. To achieve this, I had to design a Fusion 360 widget to automatically parameterize and generate crown gearboxes since I needed to translate axial motion from the motors, which is in-line with the joints, to a perpendicular motion while also controlling the exact torque profiles of the joints.

The use of custom-coded widgets was especially useful because I was computing the necessary torque profiles of the different joints through walking simulation in MuJoCo. The walking dynamics were manually defined in the beginning after a long attempt using Pinocchio.

Manufacturing

Due to budget constraints, I was only able to manufacture the hip-down parts. Below, I showcase one of the legs and the knee joint. All of the parts were manufactured from aluminum (a fastener for the ankle was steel due to shearing concerns) using a 5-axis CNC for 3D parts and a waterjet for the 2D parts.

Stress-Test

After simulating necessary joint torque values, I evaluated how well the manufactured joints matched. Compared to simulated values, the resulting torque profiles were nearly identical. Below is an interesting comparison to humanoid joint profiles, which the robotic joints universally outperformed.

FINGIE: 27 DoF Robotic Hand

Description

The goal of this project was to use creative manufacturing techniques and materials to biomechanically simulate anthropomorphic hand movements. Almost all prosthetics/robotic hands on the market are maximum of 10-13 DoF, this project aims to capture the full 27 DoF present in normal human hands.

Some Challenges

Complex Joint Dynamics: There are so many complex dynamics in the human hand. Just squeeze your metacarpals together, that's not even generally considered a degree of motion but it is! The thumb is an absolute mess with how it interacts with the trapezium (still better than the mess of bones in the foot though)! So, it was relatively obvious from the start that simple joints using bearings, bushings, etc. would be pointless since half of the joints work in multiple dimensions simultaneously anyway. So, what I became interested in what flexible resin printing (all of the white in the renders above). This enables twisting, compression, extension, etc. of what could be considered ligaments and tendons. These were wrapped around the base and end of the metacarpals and bolted into place. They were also snap-fitted to the back of the fingers and act as the grip as well on the distal joints.
Long-Range Force Communication: We know from prosthetics that EMG measurements in the palm/hand are essentially non-existent and similarly anatomically we know that the muscles responsible for hand movement are almost entirely activated and contained within the forearm. Similarly, for this project, I housed the actuators which were simple servo motors with about 10kg/cm of torque with a custom spool attachment on top. These spools were wrapped with kevlar string and routed through holes in the hand to actuate different directions. An added benefit of the flexible resin prints is that inverse movement already occurs without active actuation, so the motors only need to actuate joints in one direction in general.
Abduction & Adduction of Phlanges: If I were to return to this project, I would custom manufacture gear boxes to fit inside of the palm and between the metacarpals to do much of the hand's actuation, but I did this project when I was less confident in my mechanical engineering, so I decided instead to deal with non-tendon-actuated movement by simply carving out an area in the phalanges in the fingers and inserting a micro-servo motor which then locks its arm via jointed bolt to the end of the metacarpals, and thus achieves direct drive of the abduction/adduction motion.

Where This Ended Up

All of this project was manufactured back when was working on it, but it ended up failing because of the very low fidelity of control that I could exert on each joint. This was a combination of how I used tendons and flexible ligament structures in the design. I have given some thought to how I would redo this if I were to give it another go. Some thoughts are in this design document.
